XPeng G9 570 Max (2024) – Full Specifications

1. Performance & Powertrain

  • Drive Configuration: Rear-Wheel Drive (RWD)

  • Motor Type: Permanent Magnet Synchronous Motor

  • Max Power: 230 kW (308 hp)

  • Max Torque: 430 Nm

  • 0-100 km/h (0-62 mph): ~6.4 seconds

  • Top Speed: 200 km/h (124 mph)

2. Battery & Range

  • Battery Type: Lithium Iron Phosphate (LFP) or NMC (varies by region)

  • Battery Capacity: 78.2 kWh (usable)

  • CLTC Range: 570 km (~354 miles)

  • Charging:

    • DC Fast Charging (S4 XPeng Supercharger): 10%-80% in ~20 mins

    • Max DC Charging Power: 300 kW+ (800V high-voltage platform)

    • AC Charging: 11 kW standard

3. Dimensions & Weight

  • Length: 4,891 mm (192.5 in)

  • Width: 1,937 mm (76.3 in)

  • Height: 1,680 mm (66.1 in)

  • Wheelbase: 2,998 mm (118 in)

  • Curb Weight: ~2,200 kg

  • Trunk Space: 660 L (rear seats up) / 1,576 L (seats folded)

4. Suspension & Brakes

  • Suspension:

    • Front: Double-wishbone

    • Rear: Multi-link

    • Optional: Dual-chamber air suspension (adjustable damping & height)

  • Brakes: Ventilated discs (front & rear) + regenerative braking

5. Interior & Features

  • Seating Capacity: 5

  • Infotainment:

    • Displays: 14.96" central touchscreen + 10.25" digital cluster

    • OS: Xmart OS 4.0 (Qualcomm Snapdragon 8155 chip)

    • Audio: Dynaudio premium sound system (up to 21 speakers)

  • Connectivity: 5G, V2X, OTA updates

  • Other Features:

    • Heated & ventilated front seats

    • Massage seats (optional)

    • Dual wireless charging pads

    • Powered tailgate

    • Panoramic sunroof

6. Autonomous Driving (XPILOT 4.0 / XNGP)

  • Hardware:

    • 2x NVIDIA Orin-X chips (508 TOPS)

    • 12 cameras, 5 mm-wave radars, 12 ultrasonic sensors

  • Features:

    • Highway Navi-GP (automated lane changes, overtaking)

    • City NGP (urban autonomous driving in supported cities)

    • Memory Parking (automated parking in familiar locations)

    • Full-scenario voice assistant

7. Safety

  • Standard Features:

    • AEB (Autonomous Emergency Braking)

    • Lane Keep Assist (LKA)

    • Blind Spot Monitoring (BSM)

    • 360° camera + parking sensors

8. Price (2024 MSRP in China)

  • Starting Price: ~¥299,900 CNY (~$41,300 USD)

Key Notes:

  • The 570 Max is the entry-level Max trim, offering XPeng’s full ADAS suite (XNGP) but with a smaller battery than the 702/650 versions.

  • 800V high-voltage charging enables ultra-fast charging speeds.

  • The Max trim includes lidar and full XNGP capability, while the Pro trim has fewer autonomous features.
